The MTP/MPO patch cord and trunk cable series are an efficient and economical solution for data center environments. We provide Single Mode (SM) and Multi Mode (MM) optical patch cords with 8/12/16/24/32 cores. Trunk cables can reach up to 388 cores, with customizable options for male/female connectors, cable lengths, and colors.
| Connector | Mode | Endface | Standard Loss | Low Loss | ||
|---|---|---|---|---|---|---|
| IL(max) (dB) | RL(min) (dB) | IL(max) (dB) | RL(min) (dB) | |||
| MPO/MTP | SM | 12F/APC | ≤0.70 | ≥60 | ≤0.35 | ≥60 |
| 24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 | ||
| 48F/APC | ≤0.75 | ≥60 | - | - | ||
| MPO/MTP | MM | 12F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 |
| 24F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 | ||
| 48F/PC | ≤0.50 | ≥20 | - | - | ||
