Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
1 / 5
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable
Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable

Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable

Customization: Available
Application: Communication
Type: Single-mode Fiber
Send Inquiry

Product Description

Product Overview

Single Mode G657A2 G657A1 Fiber Pull out Distribution FTTX LSZH Jacket Fiber Optic Cable

The pull-out distribution optical cable uses single or multiple micro tubes containing ∅250µm fibers as optical communication medium. Two parallel Fiber Reinforced Plastic (FRP) are placed at the two sides as strength members, completed with a flame-retardant LSZH (low smoke, zero halogen) jacket.

Fiber Optic Cable View 1
Fiber Optic Cable View 2
Fiber Optic Cable View 3
Fiber Optic Cable View 4
Fiber Optic Cable View 5
Basic Specifications
Model NO.
Pull out Distribution cable
Material Shape
Round Wire
Core Count
2-144 Core
Sheath Material
LSZH/PVC
Fiber Brand
Yofc/Corning/Sumitomo
Fiber Model
G657A/G652D
Certifications
CE/ISO9001/TLC
HS Code
8544700000
Key Features
Excellent mechanical and environmental performance.
All dielectric and dry core structure improve efficiency and cleanness in deployment.
Small diameter and light weight for convenient installation and maintenance.
FRP strength member provides strong tension and anti-bend advantages.
High reliability data transmission and easy connectivity.
Applications
Core Network Access Network Fiber to the Home (FTTH) Building Distribution
Technical Parameters
Fiber Count Diameter Weight Bending Radius (mm) Tension (N) Crush Resistance (N/100mm)
(mm) (kg/km) Static Dynamic L-term S-term L-term S-term
2-24 6.75 33 65 130 25 40 300 600
36-48 8.5 69 90 180 30 60 300 600
48-72 10.5 97 100 200 40 80 300 600
72-96 12 132 120 240 50 100 300 600
96-144 13.5 143 150 300 60 120 300 600
Frequently Asked Questions
1. What are your main cable products?
We specialize in Outdoor/Indoor Fiber optic cables, FTTH Drop cables, ADSS, Coaxial cables (RG59/RG6/RG11), Network Data cables (CAT5/CAT5e/CAT6/CAT7), and various combination cables.
2. Do you have certificates for raw materials?
Yes, we maintain long-term partnerships with qualified ISO9001 and ROHS compliant raw material suppliers.
3. What is the typical delivery time?
Samples are usually ready in 2-3 days, while mass production orders typically take around 7-14 days.
4. What is the Minimum Order Quantity (MOQ)?
The MOQ for fiber optic cables is 2KM, and for coaxial cables is 1KM. Standard CAT5e/CAT6 cables often have stock with no MOQ required.
5. Have you worked with global operators?
Yes, we have many years of experience in cooperation and supply with various network operators.
6. What are the available shipping options?
For large orders, we ship by sea (LCL or FCL). Small orders can be sent by sea, air, or courier services depending on your preference.
