Single Mode G657A2 Invisible Bare Fiber Optic Cable for Uav Drone Sky-to-Ground

1 / 5

Single Mode G657A2 Invisible Bare Fiber Optic Cable for Uav Drone Sky-to-Ground

Send Inquiry

Product Description

Applications

Short pitch cables for special application
High performance optical network operating in O-E-S-C-L band
High speed optical routes in buildings (FTTx)
Cables with low bending requirements

Product Standards

Optical Fiber and Cable bending insensitive single mode fibre meets or exceeds the ITU-T Recommendation G.652.D/G.657. A1 including the IEC 60793-2-50 type B1.3/B6.a1 Optical Fibre Specification.

Characteristics

Low attenuation satisfying the operation demand in O-E-S-C-L band
Good bending loss resistance at short radius bends
Low bending loss for highly demanding cable designs including ribbons
Low PMD satisfying high bit-rate and long distance transmission requirements
Accurate geometrical parameters that insure low splicing loss and high splicing efficiency
Standard length: 2,000m; other lengths are also available

Specifications

Characteristics	Conditions	Specified Values	Units
Optical Characteristics
Attenuation	1310nm	≤0.35	[dB/km]
	1383nm (after H2-aging)	≤0.35	[dB/km]
	1460nm	≤0.25	[dB/km]
	1550nm	≤0.21	[dB/km]
	1625nm	≤0.23	[dB/km]
Attenuation vs. Wavelength	1285-1330nm, ref to 1310nm	≤0.03	[dB/km]
Attenuation vs. Wavelength	1525~1575nm, 1550nm	≤0.02	[dB/km]
Dispersion Coefficient	1285-1340nm	-3.5 to 3.5	[ps/(nm·km)]
	1550nm	≤18	[ps/(nm·km)]
	1625nm	≤22	[ps/(nm·km)]
Zero Dispersion Wavelength	--	1300-1324	[nm]
Zero Dispersion Slope	--	≤0.092	[ps/(nm²·km)]
Geometrical Characteristics
Cladding Diameter	--	125.0±0.7	[μm]
Cladding Non-Circularity	--	≤0.7	[%]
Coating Diameter	--	235~245	[μm]
Core-Cladding Concentricity	--	≤0.5	[μm]

Frequently Asked Questions

Are you a trading company or a manufacturer?

We are a professional factory specializing in the production of high-quality optical fiber cables.

How long is your delivery time?

Generally, it is 5-10 days if the goods are in stock. If the goods are not in stock, it is 15-20 days, depending on the order quantity.

Do you provide samples? Is it free or extra?

Yes, we can offer samples for free; however, the cost of freight is not included and should be covered by the requester.

What are your terms of payment?

Our standard payment terms are 30% T/T in advance, with the remaining balance due before shipment.

Does this fiber meet international standards?

Yes, our bending-insensitive single-mode fiber meets or exceeds the ITU-T G.652.D/G.657 standards and IEC 60793-2-50 specifications.

What is the typical application for this G657A2 fiber?

It is primarily designed for high-speed optical routes in buildings (FTTx), UAV drone sky-to-ground communication, and cables requiring tight bending radii.
