Features
- Good mechanical and environmental characteristics;
- Flame retardant characteristics meet the requirements of relevant standards;
- The mechanical characteristics of jacket meet the requirements of relevant standards;
- Soft, flexible, easy to lay and splice, and with big capacity data transmission;
- Meet various requirements of market and clients.
Application
- Used in indoor cabling, especially used in good laying conditions;
- Used in optical connections in optical communication equipment rooms and optical distribution frames, optical apparatus and equipments;
- Used in pigtails and patch cords;
Specification
| Fiber Count |
Cable Dimension (mm) |
Cable Weight (kg/km) |
Tensile (N) |
Crush (N/100mm) |
Min. Bend Radius(mm) |
Range of Temperature(ºC) |
| Long Term |
Short Term |
Long Term |
Short Term |
Dynamic |
Static |
| 2 |
2.5×3.5 |
7.3 |
80 |
200 |
200 |
500 |
50 |
30 |
-20~+60 |
| 4 |
2.5×3.5 |
7.4 |
80 |
200 |
200 |
500 |
| 6 |
2.5×4.0 |
8.2 |
80 |
200 |
200 |
500 |
| 8 |
2.5×4.5 |
9.3 |
80 |
200 |
200 |
500 |
| 12 |
2.5×5.0 |
10 |
80 |
200 |
200 |
500 |
Note: 1. All the values in the table are for reference only; 2. Cable dimensions are according to single ribbon and subject to change with ribbon count; 3. Minimum bend radius (static) is 15mm when G657 fiber is used.
Options
Fiber Type: G652, G655 or G657 single-mode fiber, A1a or A1b multi-mode fiber, or other types of fiber;
Jacket Material: PVC, LSZH, ZRPO, or other contracted material;
Jacket Color: Meets the requirements of relevant standards, or other contracted color;
Cable Dimension: Nominal or other contracted dimension;
Delivery Length: 1km or 2km, or other contracted length;
Other Requirements: Other contracted special requests.
1. What are the available fiber types for this ribbon cable?
You can choose from G652, G655, or G657 single-mode fibers, as well as A1a or A1b multi-mode fibers, depending on your specific network requirements.
2. Is the jacket material flame retardant?
Yes, the jacket options include flame retardant PVC, LSZH (Low Smoke Zero Halogen), and ZRPO, all meeting relevant safety and environmental standards.
3. What is the typical application for this indoor cable?
This cable is primarily designed for indoor cabling, optical connections in communication rooms, optical distribution frames, and for making pigtails or patch cords.
4. How does the fiber count affect the cable dimensions?
The cable dimensions vary based on the fiber count. For example, a 2-core cable measures approximately 2.5×3.5mm, while a 12-core cable measures about 2.5×5.0mm.
5. What is the allowable operating temperature range?
The flat optical fiber ribbon indoor cable is designed to operate reliably within a temperature range of -20ºC to +60ºC.
6. Can the delivery length be customized?
Yes, while standard delivery lengths are typically 1km or 2km, we can provide other lengths based on specific contract requirements.
