| Fiber type | Attenuation (dB/km) | Full injection bandwidth | Effective mode bandwidth | 10G Ethernet link length | Min bend radius (mm) | |||
|---|---|---|---|---|---|---|---|---|
| Condition | 1310/1550nm | 850/1300nm | 850/1300nm (MHZ.km) | 850nm (MHZ.km) | 850nm (m) | / | ||
| G652D | 0.36/0.22 | 0.5/0.4 | - | - | - | - | - | 16 |
| G657A1 | 0.36/0.22 | 0.5/0.4 | - | - | - | - | - | 10 |
| OM3 | - | - | 3.0/1.0 | 3.5/1.5 | >1500/500 | >2000 | <300 | 30 |
| OM4 | - | - | 3.0/1.0 | 3.5/1.5 | >3500/500 | >4700 | <550 | 30 |
| Cable type | Cable diameter (mm) | Reference weight (kg/km) | Buffer fiber diameter (mm) | Tensile Strength (N) Long/short | Crush resistance (N/100mm) | Bending Radius (mm) Dyn/Stat |
|---|---|---|---|---|---|---|
| SXC-1.6 | 1.65±0.05 | 2.6 | 0.6±0.05 | 40/80 | 100/500 | 60/30 |
| SXC-2.0 | 1.95±0.05 | 3.5 | 0.9±0.05 | 60/100 | 100/500 | 60/30 |
| SXC-3.0 | 2.85±0.05 | 6.5 | 0.9±0.05 | 60/100 | 100/500 | 60/30 |
